Original: $3,931.75
-65%$3,931.75
$1,376.11The Story
Part#
VCMP-7219-OPTI
Need a lift kit upgrade for your Mercedes Sprinter Mercedes Sprinter (2023+ 2500)? The Van Compass 2023+ Mercedes Sprinter 2500 - Opti-Rate Striker AWD 2" Complete Lift Kit (Single Rear Wheel) is built to take your adventure van deeper into rugged backcountry landscapes with confidence and control. Designed specifically for the AWD Sprinter platform, this lift kit maximizes ground clearance, tire fitment, and off-road performance while preserving factory ride dynamics.
At the heart of the system is a combination of precisely machined and welded spacers that reposition the front subframe, allowing the CVs, tie rods, and control arms to cycle properly within Mercedes’ original geometry range. This careful design ensures smooth operation, durability, and reliability, even under harsh off-road conditions.
In the rear, the innovative Opti-Rate leaf spring pack is paired with a 2" lift block, longer sway bar links, shock relocation brackets, and bump stop spacers. The Opti-Rate springs allow the end-user to fine-tune spring rate and ride height based on van weight and build specifications. They are optimized for heavily built vans in the 9,000–10,000 lb range and above, making this kit ideal for upgraded Storyteller Overlands, Revels, 170 EXT vans with heavy interior build-outs, or vans carrying additional rear axle loads like door carriers, hitch racks, and trailers.
With proper wheel offset and fender trimming, the Opti-Rate Striker AWD kit allows for fitment of up to a 35 x 12.50 tire, giving your van a significant increase in traction, ground clearance, and overall trail capability.
NOTE: With this lift kit, tires up to 35" diameter and 12.5" width can fit. Trimming of the fender liner and mud flap is required.
Key Features: Van Compass 2023+ Mercedes Sprinter 2500 - Opti-Rate Striker AWD 2" Complete Lift Kit (Single Rear Wheel
- Fits 2023+ Mercedes Sprinter AWD 2500 (Single Rear Wheel) vans only
- Front subframe repositioning preserves factory CV, tie rod, and control arm geometry
- Opti-Rate rear leaf spring pack for adjustable ride height and spring rate
- 2" rear lift block, longer sway bar links, shock relocation brackets, and bump stop spacers included
- Optimized for vans in the 9,000–10,000+ lb weight range
- Supports vans carrying heavy rear axle loads (door carriers, hitch racks, trailers)
- Allows fitment of 35 x 12.50 tires with proper wheel offset and fender trimming
- Significantly increases ground clearance and off-road traction
- Carefully engineered for minimal compromise to factory ride and handling
The Kit Includes:
- Front 2" strut spacers
- Front 2" subframe drop spacers
- Engine and transmission mount 2" lift spacers
- Front differential cam bolt kit
- CNC Machined 2" steering shaft extension
- Low pressure power steering hose extension
- Front brake line relocation brackets
- Opti-Rate Rear leaf spring pack
- 2" rear lift block
- Extended rear sway bar links
- Rear lower shock relocation brackets
- Rear bump stop drop brackets
- Wind assist or headlight leveling sensor bracket
- All necessary hardware and detailed instructions
Fitment Guide
MODEL: SPRINTER 2500
YEAR: 2013-PRESENT
DRIVE TYPE: 4X4
>>COMPLETE WHEEL AND TIRE FITMENT GUIDE<<
>>DON'T KNOW YOUR VANS WEIGHT? USE THE CAT SCALE LOCATOR<<
NOTE: With this lift kit, tires up to 35" diameter and 12.5" width can fit. Trimming of the fender liner and mud flap is required.
Recommended Wheel Size: 17" x 8.5", +45mm offset
Documents: Van Compass 2023+ Mercedes Sprinter 2500 - Opti-Rate Striker AWD 2" Complete Lift Kit (Single Rear Wheel
- 2023+ VS30 AWD Striker 2" Front Kit Installation Instructions
- Striker 2" Rear Kit with Opti-Rate Springs Installation Instructions
Video: Van Compass 2023+ Mercedes Sprinter 2500 - Opti-Rate Striker AWD 2" Complete Lift Kit (Single Rear Wheel
